Motor
Cage type capacitor structure external rotor motor
Impeller
Impact molding of aluminium alloy plate
Allowable environment temperature and humidity range:(under unconcretionary condition)
-40℃ ~ +70℃ (temperature) 0% ~ 95% (humidity)
Protection
Motor Internal with automatic recovery thermal protector
Withstand Voltage
AC 1,800V , 1 min at 0.5mA, 50/60 Hz
Insulation Grade
design according to IEC61858 Grade F,
Protection Grade
IP44
Parameters
| Type | Motor | Rated Voltage | Frequency | Power | Max Air Flow | Static Pressure | Noise | Curve | Capacitor Motor | |
| V | Hz | (W)+10% -20% | CFM | m3/h | (Pa) | (dB) | ① | (μF) | ||
| C4S-355.95 | M4S10202-AF | 115 | 50 | 1380 | 1505 | 2550 | 390 | 66 | 20.0/250 | |
| 60 | 1550 | 1711 | 2900 | 530 | 69 | |||||
| C4E-355.95 | M4E10202-AF | 230 | 50 | 1380 | 1505 | 2550 | 390 | 66 | 5.0/450 | |
| 60 | 1550 | 1711 | 2900 | 530 | 69 | |||||
| C4ED-355.95 | M4ED10202-AF | 230/400 | 50 | 1380 | 1505 | 2550 | 390 | 66 | ||
| 60 | 1550 | 1711 | 2900 | 530 | 69 | |||||
